This is a build package where all parts are new and included. No cores necessary. 1800hp capable for street use. Can be built as a 3.0, 3.2 or 3.4 liter. Available in Supra Sump, Aristo Sump, or Moroso Rear Sump.
Short Block
Labor:
Check Deck Height
Hot Tank/Clean
Paint Block, Iron
Rod Notch Cylinders
Resurface Block, Inline
Machine Fire Ring Groove
Resize Cylinder w/ Torque Plate
Resize Line Bore
Balance Crank
Assemble Short Block
Parts:
Dart Block, 1/2" Head Studs
Custom CP Heavy Duty Pistons 86mm (your choice CR)
Rods (Heavy Duty Carrillo, BC MOAR, R&R Alum)
Billet Stroker Crank (90mm, 94mm, 96mm)
ACL Race Bearing Set (Calico Coatings available for endurance engines)
Head, Stage 3
Labor:
Remove/Drill/Tap/Replace Oil Port Plugs
Plug EGR port
Stage 3 CNC Port and Combustion Chamber
Remove, Reinstall, Ream Valve Guides
Valve Job, Race
Set Valve Lash
Plug intake side water pipe
Machine Rear Water Pipe -10an ORB
Machine for 1/2" Head Studs
Resurface Head
Assemble Head
Parts:
New OEM Cylinder Head (VVTi available)
Ferrea Intake/Exhaust Valves, +1mm
Ferrea Bronze Valve Guides
Ferrea High Boost Dual Valve Spring Kit, 125lbs
Kelford DLC Coated Shimless Buckets
Ferrea Valve Locks
Ferrea Valve Seals
Kelford Cams, T202-F 282/286
Long Block
Labor:
Long Block Assemble
Spun and primed
Parts:
Apexi Grommet Type Head Gasket (Machined for 1/2" Head Studs)
Kelford Adjustable Cam Gears and bolts
ATI Super Damper
ARP Damper Bolt
Gates Racing Timing Belt
Point One H11 1/2" Head Studs
RSP Billet Tensioner Bracket
Mazworx 2JZ Engine Bolt Kit
Mazworx Engine Shipping Bracket Kit, 2JZ
New OEM Parts & Seals
OEM Water Pump
PHR Oil Pump
PHR Billet Flex Valve Covers
New OEM covers and pans
PHR Billet Valve Covers
36-2 Crank Trigger/Sprocket
Lucas Break-in Oil
